ASME B16.5 Titanium Lap Joint Flange with Stub End Loose Flange
Category:
Titanium Machined Part
Grade: Gr2 or Gr 5 .
Size Range: 1/2″ to 24″ (DN15 to DN600) .
Pressure Class: 150# to 2500# (PN10 to PN420) .
Standards: ASTM B381, ASME B16.5, ANSI, DIN, EN .
|
|
Details
Lap Joint Titanium Flange Introduction
Lap Joint Titanium Flanges are critical components in various industrial applications, designed to provide a secure and reliable connection between pipes, valves, and other equipment. Our flanges are manufactured using high-grade titanium, ensuring exceptional strength-to-weight ratio and superior resistance to harsh chemicals and extreme temperatures. Whether you’re in the oil and gas, chemical processing, or aerospace industry, our Lap Joint Titanium Flanges deliver the performance you need.
Technical Specifications
- Material: Grade 2 or Grade 5 Titanium (ASTM B381)
- Size Range: 1/2″ to 24″ (DN15 to DN600)
- Pressure Class: 150# to 2500# (PN10 to PN420)
- Standards: ASME B16.5, ANSI, DIN, EN
- Surface Finish: 32-63 RMS (standard), customizable
- Hardness: 145-170 HB (Grade 2), 300-400 HB (Grade 5)
