Standard: ASTM F67, ISO5832-2, ASTM F136, ISO5832-3.

Grade: Gr3, Gr5, Ti6Al4V, Ti6Al4V ELI

Diameter(mm): Φ16, Φ17.2, Φ18, Φ20, Φ24, Φ30, Φ40, Φ45, Φ50, Φ55, Φ65mm

Characteristic: Good elasticity, high strength, good metallographic structure, good abrasion resistance.

Shaanxi Huatainuo New Metal Materials is a leading manufacturer specializing in high-performance titanium bars for surgical implants. We supply premium-grade titanium bars and rods for a wide range of critical medical applications, including orthopedic joints, bone screws, and dental implants. Committed to excellence, we combine advanced manufacturing with extensive stock holding to be your reliable titanium products partner.

Why Choose Huatainuo Medical Titanium Bars?

Shaanxi Huatainuo specializes in the production of medical-grade titanium and titanium alloy materials for critical orthopedic implants. We have built a vertically integrated manufacturing process, from carefully selected raw materials to advanced precision testing, ensuring every bar delivers unmatched reliability and performance.

Our Controlled, Full-Process Manufacturing

1. Premium Melting & Forging: We begin with medical-standard titanium sponges, which are transformed via triple vacuum melting (using a 3-time VAR process) into a homogeneous ingot. This ingot is then forged under large-tonnage presses, achieving significant deformation that fully refines the grain structure for superior uniformity and processability.

2. Precision Size-Specific Forming:

Large Diameter Bars (Φ25-100mm): Supplied in a rolled state with over 50% deformation, followed by solution heat treatment to ensure structural uniformity, required hardness, and consistent mechanical properties.

Small Diameter Bars (<Φ25mm): Produced by a drawing process with over 60% deformation, resulting in a compact structure, excellent ovality, and straightness. This is paired with aging heat treatment to eliminate residual stress and guarantee stable, consistent performance.

Guaranteed Quality Through Rigorous Testing

Quality is verified at every stage. Every bar undergoes:

Non-Destructive Testing (NDT): Ultrasonic and eddy current flaw detection to ensure zero internal and surface defects.

Dimensional Precision: Infrared detection apparatus guarantees tight tolerances (h7, h8).

Final Treatment: All products are supplied in a vacuum-annealed state to control detrimental elements and ensure material purity.

Full Traceability: Each bar is permanently marked, establishing a complete archive for lifetime traceability.

The Huatainuo Advantage: A Summary of Excellence

Uncompromising Quality Control: A deeply ingrained culture of responsibility ensures reliability for life-critical applications.

Advanced Process Technology: Unique equipment and technics, including precision straightening and grinding machines, deliver exceptional straightness, surface finish, and dimensional accuracy.

Complete Verification: In-process and final inspections utilizing infra-ray gauges, ultrasonic, and eddy current testing validate every aspect of quality and reliability.

Partner with Confidence

Choose Huatainuo for medical titanium bars that set the standard for consistency, performance, and traceability. For more information on our company or products, please contact us.
